Eswood UT20P Passthrough Potwasher

Eswood UT20P Pass-Through Recirculating Commercial Pot & Utensil Washer

The Eswood UT20P represents the absolute pinnacle of heavy-duty, high-performance industrial ware washing, engineered specifically to handle the most punishing cleaning tasks in high-volume Australian commercial kitchens. Designed as a high-productivity pass-through system, this powerful commercial pot washer streamlines your wash house workflow by letting operators slide dirty racks in from one side and pull sanitized items out from the other. It completely removes the kitchen bottleneck, blasting away baked-on grease, caramelised proteins, and heavy starches from large cooking vessels without slow, unhygienic manual soaking.

Optimised for massive production kitchens, large commercial bakeries, centralized catering operations, busy pubs, and food manufacturing plants, the Eswood UT20P introduces unmatched processing capacity. Boasting a heavy-duty side-loading alignment with a generous 540mm vertical chamber opening clearance, it effortlessly accepts bulky mixing bowls, oversized roasting pans, stockpots, 75-litre garbage bins, and standard Australian baking trays that stall traditional pass-through dishwashers.

The best pass through pot washer in Australia the Eswood UT20P

In high-output catering and food preparation environments, managing labour constraints while maintaining strict sanitary health codes dictates daily operational profitability. The Eswood UT20P directly answers these bottom-line challenges by pairing high-volume wash and rinse pumps with independent, rotating top and bottom stainless steel spray arms. This configuration features newly engineered water jets that deliver a knife-like action, blasting and stripping heavy dirt from all soiled surfaces. Advanced wash jet balancing ensures intense cleaning pressure without damaging utensils or requiring awkward hold-down devices.

Operational compliance and data tracking are integrated seamlessly into the front user layout. Clear digital temperature displays present live wash and rinse tank data, allowing floor managers to easily log visual parameters for rigorous HACCP audits. To guarantee food safety and sanitation victory, the machine features an operation interlocked to rinse temperature, meaning a cleaning cycle cannot finish until the booster water achieves legal pasteurisation limits. Out of the box, the UT20P comes factory-equipped with a built-in wash pump and rinse pump, allowing a smooth, flexible integration into straight-line or space-optimising corner dirty-dish track lines.

Versatile Hospitality Industry Use Cases

• Commercial Production Bakeries: Rapidly clean standard Australian baking trays, bun pans, dough hooks, and large planetary mixing bowls to keep your baking rows moving.
• Large Hotels & Banquet Catering Operations: Slide racks continuously through the line to shift stubborn fats, gravies, and starches from oversized roasting trays, gastro pans, and heavy stockpots.
• Busy Pubs, Bistros & RSL Clubs: Reclaim kitchen floor space and wash large prep bowls, chef knives, whisks, and heavy-duty wire oven grids away from the main plate wash line.
• Food Processing & Production Facilities: Deploy as a high-density sanitising station to clean bulk food tote boxes, distribution bins, and 75-litre garbage containers.

Comprehensive List of Standard Features

• High-Efficiency Pass-Through Format: Accelerates cleaning workflows by sliding racks in from input benches and out onto clean sorting tables.
• Knife-Like Water Jet Action: Advanced jet designs blast and strip heavy, baked-on food remnants from all angles without causing utensil damage.
• Three Selectable Wash Programs: Features flexible factory cleaning cycles of 2, 4, and 6 minutes to perfectly match cleaning time with light or heavy soil.
• Independent Wash & Rinse Systems: Top and bottom revolving arms are built from high-grade 304 stainless steel to ensure complete coverage and erase blind spots.
• Accurate Digital Temperature Displays: Front-facing digital controller readouts present constant tank water metrics to guarantee operational oversight.
• Operation Interlocked to Rinse Temperature: A programmatic safety breaker holds back cycle completion until the booster water hits legal sanitising boundaries.
• Full Stainless-Steel Construction: Manufactured from high-quality stainless steel across the cabinet body, arms, and filters for maximum physical life.
• Standard Multi-Pump Infrastructure: Comes factory-fitted with a high-performance wash pump and an automated rinse booster pump as standard components.
• Easily Removable Filter Panels: Wide-surface internal stainless steel filter trays slide out smoothly by hand for prompt cleaning and pump protection.
• One-Touch Start Sequence: Streamlines kitchen operation by launching complete automatic wash sequences with the simple push of a button.

Technical Specifications

Dimensions, Clearances & Capacity

• External Width: 805mm
• External Depth: 855mm
• External Height (Door Closed): 1760mm
• External Height (Door Open): 2195mm
• Chamber Vertical Opening Clearance: 540mm
• Internal Wash Chamber Layout: W665mm x D630mm x H540mm
• Heavy-Duty Rack Size & Opening: W660mm x D610mm x H540mm
• Internal Wash Tank Liquid Volume: 70 Litres
• Fresh Water Consumption Rate: 5 Litres per rack cycle
• Hourly Output Rating: Processes up to 25 racks per hour

Power, Water & Plumbing

• Electrical Connection Requirement: 3 Phase – 415V + N + E
• Total Power Load Rating: 13.5 kW
• Current Connection Infrastructure: Hardwired 3-phase electrical installation line
• Water Connection Input: 1/2” BSP hot water supply line connection
• Drain Connection Output: 2” BSP waste connection outlet (Standard gravity drain setup)
• Water Supply Feed Parameters: Recommended incoming hot water supply at 65°C under 1-4 bar (15-58 psi) pressure

Cleaning & Preventative Maintenance

The Eswood UT20P is purpose-engineered to take the hassle out of kitchen closing procedures and preserve internal pumping line assemblies over years of service:

• Toolless Component Detachment: Upper and lower stainless-steel wash and rinse arms can be unclipped manually without specialized tools for rapid cleaning of the spray jets.
• Accessible Filtering Matrix: Dual wide-surface 304 stainless steel filter panels slide out smoothly by hand, keeping heavy waste soils safely trapped above the drainage well for quick sink rinsing.
• Seamless Internal Basin Layout: Crevice-free internal surfaces reduce food waste traps, grease buildup, and bacteria accumulation.
• Durable Mechanical Door Gaskets: High-grade rubber perimeter seals hold firmly against hot moisture escape and pull free easily for prompt sanitation wipe-downs.

Warranty, Standards & Compliance

• Premium Manufacturer Warranty: Covered by a comprehensive commercial parts and labour warranty backed direct by Eswood Australia for true long-term operational protection.
• HACCP International Food Safety Certified: Tested, reviewed, and certified by HACCP International, confirming total compliance for installation in active food production areas.
• FSANZ Safe Food Code Compliant: Tested and certified to maintain the exact thermal pasteurisation values demanded by Australian national safe food handling mandates.
• Watermark Approved Layout: Officially certified and stamped under national Watermark regulatory guidelines, ensuring a legal and secure connection to public water mains.
• Proudly Australian Made: Designed and manufactured in Eswood’s specialized Sydney factory located in Smithfield, NSW, using locally stocked parts.

Frequently Asked Questions (FAQs)

Q: Can this pass-through pot washer run off a standard 15-amp single-phase power plug?
A: No. The UT20P features high-performance 13.5 kW elements and heavy-duty industrial pumps that require a hardwired 3 Phase 415V electrical supply connection.

Q: What is the primary benefit of choosing the pass-through model over a standard front-loading unit?
A: The pass-through configuration allows loaded racks to easily slide in from side feeder benches and slide out again after washing. This creates a linear, high-efficiency workflow that keeps dirty and clean ware completely separated.

Q: Does this model include an internal drainage pump assembly?
A: The standard UT20P configuration is built as a gravity-drain system via a 2” BSP waste line. If your commercial kitchen plumbing features an elevated wall waste trap, a specialized internal drain pump must be factory-fitted.

Q: Will standard 500x500mm dishwasher racks fit inside this machine?
A: Yes. While it is built to hold large pots, baking trays, and garbage bins on its spacious 660x610mm tracking layout, standard 500x500mm washing baskets can easily be slid inside to run rapid cycles of kitchen utensils or smaller prep bowls.

Q: Why does the machine feature an operation lock tied to rinse temperatures?
A: This built-in safety interlock pauses the cleaning loop countdown if the booster tank water drops below required levels, guaranteeing that the final rinsing stage always achieves the exact thermal sanitising temperature needed to satisfy local health councils.
