Washtech M2 Passthrough Dishwasher with 500mm Rack
The Washtech M2 Passthrough Dishwasher is a premier heavy-duty ware washing solution engineered to sanitise up to 1,080 plates per hour in demanding hospitality environments. Built specifically to withstand fast-paced Australian food service operations, this commercial pass-through dishwasher combines high-efficiency 60, 120, and 180-second wash cycles with a resource-conscious 2.4-litre water consumption rate per cycle.
Designed to create an ergonomic, high-output washing workflow, the Washtech M2 accommodates standard 500mm racks and seamlessly integrates with standard kitchen benching. By eliminating manual lifting and accelerating tableware turnaround times, this robust unit helps hospitality venues protect stock, reduce physical strain on staff, and maintain flawless food safety compliance during peak service rushes.
High-Performance Efficiency for Demanding Wash Stations
The primary operational advantage of the Washtech M2 is its ability to turn a hectic dishwashing area into a smooth, linear pass-through station. Positioned between stainless steel inlet and outlet benches, it allows kitchen hands to slide 500mm racks directly from sorting to washing without lifting, improving staff safety, and drastically lowering the risk of accidental tableware breakages.
Powered by a premium 1.0HP soft-start wash pump, the machine protects fragile glassware while delivering high-pressure cleaning action that easily strips away baked-on grease and stubborn food residues. To ensure maximum hygiene, the unit features an assured rinse system backed by an integrated break tank and booster pump. This design guarantees a constant, sanitising rinse temperature regardless of fluctuating building water pressure.
High-Volume Hospitality and Industry Use Cases
- Busy Cafes and Bistros: Rapidly process up to 40 racks of dishes per hour during peak breakfast and lunch rushes, keeping your tabletops fully set while minimizing your physical plate inventory.
- Pubs, Clubs, and Restaurants: Clean heavily soiled plates, cookware, and glassware on the ultra-fast 60-second rapid cycle during high-turnover weekend dinner services.
- Hospitals and Aged Care Facilities: Achieve verified thermal sanitisation standards to safeguard vulnerable residents, supported by precise temperature management and automated chemical delivery.
- Caterers and Function Centres: Cycle through hundreds of wine glasses, dessert plates, and bulky platters between banquet courses without creating operational bottlenecks.
Operational Advantages and Core Benefits
- Assured Rinse Technology: The built-in break tank and booster pump guarantee a precise, compliant rinse cycle every time, even in buildings with low water pressure or cold inlet water.
- Advanced Touchscreen Controls: Features an innovative touchscreen interface with a versatile Heads-Up Display, allowing operators to monitor cycle progress and system parameters instantly.
- Updateable Power Options: Offers flexible, up rateable power wiring paths to support rapid rinse recovery, making it perfect for back-to-back high-volume washing sessions.
- Hands-Free Waste Drainage: The integrated sump and automatic drain pump handle wastewater discharge effortlessly, eliminating manual tank draining protocols.
- Flawless Chemical Calibration: Dual built-in chemical pumps automatically inject precise amounts of commercial detergent and rinse aid, ensuring streak-free drying without operator guesswork.
Key Features
- Three Wash Cycle Speeds: Choose from 60, 120, or 180-second programmable washing cycles based on soil loads.
- Versatile Bench gap Compatibility: Flexible physical footprint aligns seamlessly with 595mm to 640mm bench gaps.
- Soft-Start Wash Pump: The 1.0HP pump soft-starts to prevent fine China and delicate glassware from shifting or breaking during high-pressure cycles.
- Two-Stage Filtration System: Assembled with heavy-duty stainless-steel wash and drain filtration alongside a robust stainless-steel manifold.
- Flexible Control Mounting: The supplied touchscreen control bracket allows for easy installation on either side of the machine, under the bench, or directly on the wall.
Technical Specifications
Dimensions and Capacity
- Machine Width: 730 mm
- Machine Depth: 710 mm
- Machine Height: 1530 mm
- Machine Weight: 94 kg net (Packed weight: 125 kg)
- Internal Volume: 0.91 m³
- Maximum Cleaning Output: Up to 1,080 plates per hour / 40 racks per hour
Power and Electrical Requirements
The Washtech M2 features up rateable electrical options to match your venue’s infrastructure:
- Single Phase: 230-240V, 50Hz, 15 Amp (Maximum 3.75 kW)
- Three Phase: 400-415V, 50Hz, 15 Amp per phase (Maximum 9.00 kW)
- Note: An isolating switch must be positioned within 1 metre of, and not directly behind, the machine.
Water and Drainage Specifications
- Hot Water Connection: 3/4” male thread, flexible inlet hose supplied
- Inlet Feed Temperature: Recommended 65°C (Suitable for connection to low inlet water temperature, flow, and/or pressure supplies)
- Water Pressure Parameters: 100–500 kPa
- Water Flow Volume: 10 Litres per minute
- Drainage Type: 25mm flexible drain pump hose
Inclusions
Every brand new Washtech M2 passthrough dishwasher includes:
- 1x 500mm heavy-duty dish rack (Part Number: 600 70028)
- 1x 500mm non-scratch cup rack (Part Number: 600 70029)
- 1x Hardwearing cutlery container (Part Number: C660503)
- 1x Complete quick connection kit featuring all supply hoses and a single-phase 15A plug set
Cleaning and Maintenance Section
Enforcing daily cleaning protocols extends the operational life of your Washtech M2 and prevents unscheduled breakdown downtime:
- Clear Scrap Filters Daily: Remove the two-stage stainless steel wash and drain filtration inserts at the end of every service shift and knock out collected food waste.
- Rinse the Filter Mesh: Wash the stainless-steel filter pieces thoroughly under warm running water to remove fine grease build-up.
- Inspect the Arms: Check the independent upper and lower stainless-steel wash and rinse arms periodically. Clear any blocked water jets using a pin or small brush.
- Purge the Tank Nightly: Use the automatic hands-free drainage system to empty the wash tank completely at close. This step ensures a clean internal environment and fresh water for the next day’s operation.
Warranty and Compliance
Distributed throughout Australia by Moffat PTY Limited, the Washtech M2 is backed by an exceptional 5-2-1 Warranty Program:
- 5 Years parts warranty covering the structural tank framework.
- 2 Years parts warranty on the wash pump motor.
- 1 Year full parts and labour warranty across the entire unit.
The machine is fully Water Mark certified and includes an integrated atmospheric vacuum breaker to ensure total backflow prevention compliance with Australian commercial plumbing codes.
Why the Washtech M2 is Ideal for Commercial Kitchens
Commercial kitchens cannot afford a breakdown at the wash station. The Washtech M2 is a premier choice because it combines heavy-duty New Zealand manufacturing with cutting-edge electronics designed for harsh environments. While its touchscreen controls provide a clear, modern interface for staff, its underlying mechanical structure uses independent stainless-steel arms and manifolds to ensure lasting reliability.
The layout options are highly versatile. It can be installed as a straight inline pass-through machine or nestled into a corner layout. For corner installations, ensure racks are pushed directly into the back of the machine. This orientation keeps the versatile touchscreen accessible, while allowing a 300mm front clearance for quick servicing access and keeping splashback returns under 150mm.
Frequently Asked Questions (FAQs)
Q: Can the Washtech M2 run on a regular 15A single-phase power plug?
A: Yes. The machine comes equipped with a standard single-phase 230-240V, 15 Amp plug set out of the box, drawing a maximum of 3.75 kW. For heavy-duty locations requiring ultra-fast cycle recovery times, it can be re-wired to a 15 Amp per phase three-phase configuration (9.00 kW).
Q: What water pressure is required for this commercial dishwasher to operate?
A: The Washtech M2 operates across a wide pressure spectrum of 100 kPa to 500 kPa. Thanks to its integrated break tank and booster pump, it delivers a highly consistent, compliant rinse even on low-pressure site supplies.
Q: Does the unit require an external gravity drain line?
A: No. The Washtech M2 is equipped with a hands-free drainage system that features a specialized sump and built-in drain pump. It ships with a 25mm flexible drain hose that pumps wastewater out cleanly even if your building plumbing connection is elevated.
Q: Where can the touchscreen control panel be mounted during installation?
A: The machine includes a specialized bracket that allows the touchscreen and Heads Up Display to be installed on either side of the dishwasher hood, mounted under the benching, or fixed directly to the wall for optimal ergonomics.
Q: Can this pass-through dishwasher be installed directly into a corner?
A: Yes, it is perfectly suited for corner installations. When setting it up in a corner, arrange the layout so racks are pushed into the back of the machine. Ensure you leave a 300mm clearance at the front for maintenance and limit your splashback return height to 150mm.
