Washtech GM-R Undercounter Polish Free Compatible Glasswasher

Washtech GM-R Professional Compact Undercounter Glasswasher

The Washtech GM-R Professional Compact Undercounter Glasswasher is a space-saving, heavy-duty commercial undercounter dishwasher unit built purposefully to satisfy the strict requirements of tight Australian hospitality layouts. Merging a downsized structural chassis with flexible multi-cycle capabilities, this durable 450mm rack commercial glasswasher functions as a highly reliable under bench cleaning station. It is engineered to process up to 960 clean glasses every hour without sacrificing valuable floor space. Distributed throughout Australia by Moffat, the Washtech GM-R features high-performance touchscreen controls, an automated hands-free drainage system, and dual chemical injection pumps to secure immaculate wash results on every single run.

Optimised for high ends Bars and Restaurants

In a bustling food service venue, bar counter space is strictly limited, and rapid turnaround of clean glassware keeps profits flowing. The Washtech GM-R addresses this industry hurdle by packing full-scale performance features into a lowered, space-conscious configuration. Its highly adaptable interior cabinet allows bartenders to maintain an efficient workflow right at the service point.

This compact glasswasher offers immediate operational advantages across a wide range of hospitality applications:

• Micro-Bars and Speakeasies: Slides effortlessly under low-profile front bars to maintain a steady flow of clean cocktail glasses without breaking the venue’s design aesthetic.
• Espresso Bars and Kiosks: Manages a constant influx of ceramic coffee cups, saucers, and specialty latte glasses in confined workspaces.
• Wineries and Cellar Doors: Safeguards delicate wine tasting stems while removing stubborn lipstick marks and organic residues.
• Boutique Hotels and Lounges: Serves as a localized secondary glass cleaning station to support busy floor staff during evening rush hours.

Key Benefits and Operational Advantages

• Compact Footprint: With a reduced width and lowered height profile, this machine easily clears tight under bench obstacles that block traditional commercial dishwashers.
• Flexible Basket Accommodation: Designed to securely hold standard 450mm ware washing baskets, with internal support runners that adjust down to hold 365mm racks.
• Fast Cycle Options: Pick between 1, 2, and 3-minute washing cycles depending on the venue’s immediate volume needs and soil intensity.
• Controlled Water Consumption: Consumes an ultra-low 2.4 litres of hot water per wash cycle, directly minimizing chemical usage and monthly operational overheads.
• Streamlined Digital Operation: An intuitive touchscreen panel provides real-time cycle tracking and simple operational inputs for rotating staff members.

Premium Features & Heavy-Duty Engineering

• Low-Impact Soft Start Pump: Equipped with a specialized 0.3HP wash pump that ramps up water pressure gradually to prevent expensive glassware from colliding and chipping.
• Separated Wash & Rinse Arms: Employs independent stainless-steel top and bottom wash and rinse mechanisms to achieve uniform water distribution.
• Internal Drainage Pump: Houses a reliable hands-free drainage layout that pumps out wastewater automatically, avoiding the setup constraints of gravity outlets.
• Rapid Heat Recovery Engine: Built with up rateable electrical components to accelerate rinse water temperature recovery between back-to-back washing cycles.
• Heavy-Gauge Stainless Steel: Built out of premium, heavy-duty stainless-steel panels to ensure long-term structural integrity in damp bar conditions.

Technical Specifications

• Equipment Type: Professional Compact Undercounter Glasswasher
• Model / SKU: Washtech GM-R
• Rack Compatibility: From 365mm up to standard 450mm x 450mm racks
• Wash Cycles: 1, 2, and 3-minute selections
• Hourly Output Capacity: Up to 960 glasses per hour
• Water Consumption: 2.4 Litres per cycle
• Wash Pump Motor: 0.3HP pump with soft start wash protection
• Net Volume: 0.33 cubic metres
• Packed Weight: 57 kg
• Inclusions: 1x 450mm dish rack, 1x 450mm cup rack, 1x cutlery container, and 1x quick connection plumbing kit.

Dimensions

• External Width: 500 mm
• External Depth: 600 mm
• External Height: 780 mm

Power & Electrical Requirements

• Electrical Supply: 230-240V, Single Phase, 50Hz
• Power Configuration: Modular up rateable rinse element system for rapid temperature recovery

Warranty and Compliance

The Washtech GM-R satisfies all strict Australian commercial water safety and electrical requirements. It comes backed by Moffat’s comprehensive 5-2-2 industry warranty support:

• 5 Years structural coverage on the Stainless-Steel Cabinet panels
• 2 Years on the Wash Pump mechanical components and labour
• 2 Years comprehensive Parts and Labour coverage across the entire unit

Daily Cleaning & Routine Maintenance

Keep your equipment running efficiently and ensure crystal-clear glassware by following this quick daily checklist:

1. Empty the Tank: Use the built-in, hands-free drainage controls to empty the wash chamber at the close of business.
2. Rinse the Scrap Filters: Pull out the interior stainless steel filter trays, clear out any trapped debris or toothpicks, and wash them under fresh water.
3. Check the Spray Jets: Confirm that the independent wash and rinse arms spin freely and are clear of lime scale or seed obstructions.
4. Wipe down Inner Surfaces: Wipe clean the interior door lining and rubber safety gasket with a non-abrasive damp cloth to prevent mildew.

Why Choose the Washtech GM-R For Your Bar or Restaurant?

Standard commercial under bench washers often struggle to slide under modern, lowered Australian bar configurations, forcing venues to install smaller domestic appliances that cannot heat water to regulatory sanitising temperatures. The Washtech GM-R solves this layout crisis completely. Measuring just 780mm in height, it fits into tight spaces where larger 840mm units cannot go, yet it still delivers true commercial-grade heating, integrated dual chemical pumps, and lightning-fast wash cycles. It provides a professional-tier ware washing workflow for compact venues that refuse to settle for compromised performance.

Frequently Asked Questions (FAQs)

Q: Will this glasswasher fit under a low-profile bar setup?
A: Yes. The GM-R features an overall external height of just 780mm. This makes it significantly shorter than standard 840mm commercial undercounter units, letting it slip under lowered benches and compact service areas easily.

Q: What does the soft-start pump motor do for my glassware?
A: The 0.3HP wash pump avoids throwing full water pressure at your glassware instantly. By stepping up the spray velocity gently over the first few seconds of the wash cycle, it prevents delicate cocktail saucers and highball glasses from tipping over and shattering.

Q: Does this compact model include automated chemical dispensing?
A: Yes. The Washtech GM-R features integrated dual internal chemical pumps. The machine draws liquid detergent and rinse aid straight from your bulk bottles and automatically doses the wash tank, saving bar staff from handling harsh chemicals manually.

Q: Can I connect this machine to a cold-water line?
A: The GM-R requires a hot water connection to ensure it meets rapid sanitising turnarounds. If your site only has a cold supply, you can utilize the machine’s up rateable power capabilities to help boost heating recovery times.

Q: What specific baskets are shipped out with this glasswasher?
A: Every factory-sealed Washtech GM-R unit comes standard with a full quick-connection plumbing installation kit, a cutlery container, 1x 450mm dish rack, and 1x 450mm cup rack.
